Description

Infutek i9 series Syringe Infusion Pump is a basic equipment for : Intensive
care units (ICU), operating theaters, emergency, anaesthesiology,
cardiology, neonatology, paediatrics, oncology and general hospital wards.
Ideally suited for administration of anti‐cancer drugs, chemotherapy
medication, anaesthesia & life saving drugs.

FEATURES:
Compact and light weight design
Precise occlusion pressure settings
Real time display and more than 80,000 history records
Supports 5, 10, 20, 50(60)ml syringes
Dynamic pressure surveillance (DPS)
Upgradable to PCA (Patient Control Analgesia) mode (optional)
Day / Night Mode
Drug library with more than 100 nos. of commonly used drugs and can be
user defined.
Multiple modes of operation to suit clinical demands of infusion
Longer battery backup
Auto purge / Bolus facility
KVO Mode

DISPLAY (Large colour TFT)

INFORMATION SHOWN: Delivery date, current infusion, VTBI, total volume, syringe size, syringe brand,
battery capacity, alarms, adjustable brightness control (1-99 levels)

APPLICABLE SYRINGES

Disposable sterile syringes: 50/60, 30, 20, 10, 5ml and 2/3ml (optional)Pre-configured 16 brands and
possibility of 4 new custom syringe brands by userAutomatic syringe size detection

INFUSION MODE

Rate mode, Time mode, Micro infusion mode, Body weight mode, Ramp up/Ramp down mode(optional),
Sequentialmode(optional), PCA mode (optional)

ACCURACY Wide beam pulse doppler

FHR MEASUREMENT RANGE 30-240 bpm (US STANDARD) 50-210 bpm (EUROPE STANDARD)

ACCURACY ±1% (Under specific conditions)

INFUSION RATE

5ml Syringe 0.1-120 ml/h, in steps of 0.1 ml/h10ml syringe 0.1 – 300ml/h, in steps of 0.1ml/h20ml syringe 0.1 –
600ml/h, in steps of 0.1ml/h50/60ml syringe 0.1 – 1800ml/h, in steps of 0.1ml/h(0.01ml/h increment step is
optional)

VOLUME TO BE INFUSED 0~999.99 ml, in steps of 0.01ml

VOLUME INFUSED 0~999.99 ml

KVO RATE 0.1 – 10ml/h, in steps of 0.1ml/h (Default 0.1ml/h)

BOLUS(ml/hr)

Automatic/Manual bolus rate programmable upto 1800ml/h (depending on syringe size)Bolus dose
programmable upto 999.99ml
